SPARK 150

Rolling shutter automation for residential or industrial use up to 160kg

Product description
Technical leaflets

Spark series is rolling shutter automation for residential or industrial use. It is suitable for rolling shutters up to 160kg. It contains the unlocking cable that is up to 5m. Integrated limit switches allow precise adjustment of the shutter opening and closing positions.

Technical data

Maximum gate weight : 160kg
Power supply : 230V
Motor power: 520Watt
Maximum thrust: 150Ν
Motor speed: 10RPM
Diameter winding flange: 200-220mm
Diameter drive shaft: 40mm-60mm

CE_SPARK.pdf
