TRITON 15

Sliding door motor for doors up to 1500 kg, prewired Profelmnet control panel

Triton 15 is a sliding gate motor. It is powerful, quiet, with a compact design. Perfect for either wrought iron or solid timber sliding gates, for maximum door weight up to 1500 kg. Embedded the pre-wired Profelmnet's control panel, covering all requirements for the best function of the motor.

ProfelmNet

Technical data

  • Maximum door weight   1500 kg
  • Motor power   230V/550W
  • Opening time  11-13 meters / minute
  • Motor rpm  1400
  • Protection rating  IP44
  • Weight 17 kg
ProfelmNet

Main control board functions

  • Separate limit switch inputs for the motor
  • External button: N.O contact
  • Photocell contact input at 24VAC/1,1VA
  • Adjustable electronic motor torque
  • Output for flashing light 230VAC/25W standard with or without intermittence
  • Auto-close feature: Smart auto-close timer
  • Motor operating time: Programmable from 1 to 180 seconds
  • After a power outage, the control panel checks if the door is close or open and it closes it automatically
  • Working temperatures: -20 to +60 Celsius
